1. Trailer Materials:
Chassis: Constructed from double hot dip galvanized RHS steel (3.5mm-4.0mm), ensuring maximum strength and resistance to corrosion.
Frame: The frame is made from double hot dip galvanized RHS (2.5mm), providing a robust structure that can withstand heavy use.
Body Panel: Crafted from galvanized steel (1.2mm) to enhance durability.
Roof: Special molded FRP (Fiber Reinforced Plastic) offers a lightweight yet strong covering.
Nuts & Bolts: All fittings are stainless steel, ensuring longevity and resistance to rust.

2. Wheels & Tyres:
Wheel Rim: Fitted with 15" aluminum alloy rims, combining lightweight design with strength.
Tyres: Equipped with four Light Commercial tyres for reliable road handling.
Spare Wheel: Comes with one spare wheel for emergency situations.

3. Axles & Suspensions:
Axles: Two specially designed trailer axles provide stability and weight distribution.
Suspension: Features roll rocker tandem spring suspension with six plates for a smooth ride, minimizing impact from uneven surfaces.
Brake System: Utilizes a 4 wheel axle electric brake for enhanced safety and stopping power.

4. Windows & Doors:
Front Window: Dimensions of 1220mm x 610mm for visibility and ventilation.
Side Windows: sliding windows with bars and flyscreens, ensuring airflow and light.
Vents: Double sash casement vents allow for adjustable airflow.
Side Door: Size of 1755mm x 615mm for easy access.
Rear Upper Door: Measures 2020mm x 1065mm, providing additional entry options.
Ramp Door: A large ramp door (2020mm x 1210mm) for smooth loading and unloading.
Struts and Hinges: High-intensity anti-rust struts and special 6mm diameter copper hinges for durability and ease of use.

5. Drawbar:
Drawbar: aluminum for strength and protection.
Safety Chain: Two chains are included for added security.
Bracing Wheel: One bracing wheel provides stability when parked.

6. Lights & Retro Reflectors:
Trailer Plugs: Fitted with square 7 pin plug for easy connectivity.
Lighting: Equipped with LED group rear lamps for visibility during night travel.
Stand: Aluminum rear lamps stand for durability.
Reflectors: Retro reflectors enhance visibility for safety.

7. Mudguard:
Type: Full width mudguard to protect from road debris.
Material: Checker plate 1.2mm aluminum on the front for added durability.
Pedal & Step: Features a 1.2mm aluminum decoration board for aesthetic appeal.

8. Interior & Exterior Features:
Living and Horse Area: A full wall divides the living space and horse area, ensuring comfort and safety.
Horse Safety: The horse protection frame is fully padded to ensure comfort during travel.
Horse Rings: Equipped with five horse rings for secure tie-up.
Rubber Matting: 12mm rubber matting on the ramp door and floor for slip resistance, along with 6mm rubber matting on the inner side panels.
Floor: The floor is  made from 2mm Aluminium plank.
Rug Rack: Enclosed with gas struts for ease of open and close.
Saddle Rack: Lined with marine carpet and adjustable saddle brackets x 3 with a height of 1500mm.
Painting Options: Available in single-tone or customized finishes to suit personal preferences.
